SPL TITANIUM Rear Lower Camber Arms - FR-S / BRZ / 86 & 08-14 Impreza WRX, STi / 15+ WRX, STi

Regular price $692.10 USD Sale price $692.10 USD Regular price $769.00 USD
Sale 10.0% $76.90 USD (10.0%)
Special order - Ships in 5+ weeks
SKU: sppSPL RLL FRS
Product Description
The SPL TITANIUM Rear Lower Camber Arms for the 13-16 Scion FR-S, 13+ Subaru BRZ, 17+ Toyota 86, 08-14 Subaru Impreza WRX, 08-14 Subaru Impreza WRX STi, 15+ Subaru WRX, and 15+ Subaru WRX STi increase rear stability and response by eliminating bushing deflection. It also provides a wide range of camber adjustment ensuring the perfect alignment for every need.

These arms are designed for use in high performance street and race vehicles, especially those that are lowered and need a wide range of camber adjustment. Without factory camber adjustment a lowered FR-S/BRZ requires an adjustable control arm to achieve your desired alignment settings to maximize tire wear and handling. The Arms come with three position mounting holes for sway bar end links & shock mounting, this allows you to alter geometry to prevent end link binding and quickly adjust motion ratios. In layman terms, it’s like having adjustable spring rates without a spring replacement.

Using FEA (Finite Element Analysis) our CNC milled 6061 billet aluminum arms are designed to exceed factory strength and durability. The SPL exclusive hybrid adjuster is comprised of electroless nickel plated 4130 chromoly, titanium hardware, and 6061 aluminum clamps to reduce weight without compromise.

Applications:
  • Subaru Impreza WRX [GH / GE / GR / GV] (2008, 2009, 2010, 2011, 2012, 2013, 2014)
  • Subaru Impreza WRX STi [GR / GV] (2008, 2009, 2010, 2011, 2012, 2013, 2014)
  • Subaru BRZ [ZC6] (2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020)
  • Scion FR-S [ZN6] (2013, 2014, 2015, 2016)
  • Subaru WRX [VA] (2015, 2016, 2017, 2018, 2019, 2020)
  • Subaru WRX STi [VAB] (2015, 2016, 2017, 2018, 2019, 2020)
  • Toyota 86 [ZN6] (2017, 2018, 2019, 2020)

***Allows for headlight level function/mount to be installed on the 2015+ Subaru WRX STi***

Features

Lightweight aluminum, titanium, and chromoly construction
Electroless nickel plated 4130 hybrid adjuster for quick adjustment
Computer Aided Design with the aid of Finite Element Analysis
Low friction 3-piece Teflon lined FK Heim joints/rod ends made in the USA
Multiple mounting points for shock and sway bar provides motion ratio adjustment
CAD plated grade 10.9 hardware
Made in the USA

Extended Information

Type: Rear Camber Arms
Adjustment: Camber
Chassis: ZN6 / ZC6 / GV / GE / GR / GH / VA
Engine: FA20 / EJ25
Notes: n/a
