- RELIABLE PERFORMANCE -- Precise roll-form design ensures consistent and optimal factory-installed preload to minimize excessive noise and wear
- EXTENDED SERVICE LIFE -- Application-specific advanced raceway design reduces stress, rotation and heat on components
- KEEPS WATER AND DIRT OUT -- Quad lip seal design inhibits damage by keeping moisture and other contaminants out
- EASY TO INSTALL -- Engineered and designed for fast, hassle-free installation
- CORROSION PROTECTION -- Coated wheel studs resist corrosion and rust for easier removal and proper torqueing
- RIGOROUS TESTING -- Comprehensive testing throughout design and development processes by MOOG engineers for quality you can count on
SPECIFICATIONS
- Spline Quantity 29
- Flange Offset (MM) 45.100
- Flange Diameter (MM) 171.200
- Flange Bolt Hole Quantity 3
- Wheel Pilot Diameter (MM) 77.600
- Brake Pilot Diameter (MM) 89.900
- Wheel Stud Quantity 6
- Hub Pilot Diameter (MM) 89.000
- Flange Shape TRIANGLE
- Anti Lock Brake Sensor Included Yes
- Bolt Circle Diameter (IN) 5.500
- Bolt Circle Diameter (MM) 139.800
