ICON 2024 Toyota Land Cruiser 250 Series Stage 2 Tubular Suspension System, 1.25-3in Lift (K53362T)
ICON Vehicle Dynamics has developed suspension systems for the 2024 Toyota Land Cruiser 250 Series with a focus on maximum performance for serious drivers. The primary goal of ICON engineers is to enhance wheel travel and damping capacity, resulting in excellent vehicle control and ride quality on both paved roads and off-road terrains. The Stage 2 system features vehicle-specific tuned 2.5 Series coilover shocks, which include internal reservoirs for exceptional cooling performance. It also incorporates ICON-engineered coil springs that provide superior vehicle “feel” throughout the range of travel. These coilovers are height adjustable, allowing for a front lift of 1.25 to 3 inches over stock, making it possible to install larger and more aggressive wheel and tire combinations. To optimize available front suspension travel and prevent CV joint binding, the system includes front differential drop brackets and uniquely designed coilover lengths. Additionally, polyurethane differential mounting bushings replace the soft original equipment (OE) bushings to limit differential movement under load.
The ICON tubular upper control arm kit is designed to enhance the overall performance of the Land Cruiser by correcting front-end geometry, adding caster, and improving clearance for suspension components. Additionally, replacing the original equipment (OE) ball joint with the new, serviceable, and rebuildable ICON Delta Joint PRO allows for full bump and droop travel of the front suspension while eliminating binding. The dual-rate rear coil design features a softer ride height spring rate combined with a firmer overload rate, delivering both on-road comfort and excellent bottoming resistance, as well as superior off-road performance. The kit offers a 2-inch rear lift over stock, providing a level stance both front and rear. ICON 2.0 Aluminum Series internal reservoir rear shocks are equipped with vehicle-specific valving, ensuring balanced performance throughout the truck. The ICON Vehicle Dynamics 2024 Toyota Land Cruiser 250 Series Stage 2 suspension system is an outstanding choice for drivers looking to enhance their vehicle's capabilities both on the road and off-road.
Application
- Toyota Land Cruiser 250 (2024)
Features
- Vehicle specific tuned front and rear shocks for superior shock damping and control
- Increased wheel travel and improved ride quality over stock
- Front differential drop provides better maximum operating angle for CV joints and maximizes available wheel travel
- Adjustable coilovers provide 1.25-3" front lift height over stock
- Tubular UCAs for added strength, durability, and alignment correction for better drivability
- UCAs feature the patented (U.S. Pat. 10,731,700) Delta Joint Pro with 90 degrees of total articulation
- 6061 aircraft grade aluminum CNC machined components
- Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts
- Dual rate rear coil springs improve performance and ride quality while providing 2" of rear lift
- FK Rod End bearings for extended longevity and minimal deflection
- 2.0 Aluminum Series internal reservoir rear shocks with 5/8" shafts
Tech Information
- OEM Wheels & Tires Fitment: Yes
- Recommended Aftermarket Wheels: 17x8.5 with 6.32” Backspace / 40mm Offset
- Recommended Aftermarket Wheels: ICON Alloys - 18x9 with 6.6” Backspace / 40mm Offset
- Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
- APPLICATION NOTE #55: Shocks are fully serviceable. Lift heights indicated are for a stock equipped vehicle.
- APPLICATION NOTE #85: Advertised lift height ranges are for a stock equipped vehicle. Increasing weight of vehicle due to accessories will alter lift range.
